JA standing server rack — 25U / 42U / 48U 19-inch server cabinet
The JA is our workhorse 19-inch floor-standing server cabinet for data rooms, telecom sites and integration projects. It carries an 800 kg static load, ships in 25U, 42U and 48U heights, and takes 600 or 800 mm widths at 800 or 1000 mm depths — enough matrix to standardize a whole project on one platform.
- Rack units25 / 42 / 48U
- Width × Depth600·800 × 800·1000 mm
- Static load800 kg
- Flat-pack from0.279 m³
More racks per container. Per-model assembled and flat-pack volumes in the table below.
Built for the job
- Split side panels — two per side — each locking independently, so a technician can open one half for cabling without exposing the rest of the cabinet.
- Curved perforated front screen door and double perforated rear doors for front-to-back airflow across dense server loads.
- 800 kg static load on a 2.0 mm cold-rolled steel frame and beams, with 1.5 mm profile rails.
- Multifunctional cable-routing panels inside; grounding continuity and U-marked mounting columns as standard.
- Casters and M12 levelling feet ship together — roll it into position, then set it down level.
- Optional bases for fixing, cable entry, ventilation and rodent protection.
Models & dimensions
Transcribed from the factory spec sheet. Assembled and flat-pack carton volumes let you compare container loading directly.
| Model | U | W × D (mm) | Height (mm) | Assembled (m³) | Flat-pack (m³) |
|---|---|---|---|---|---|
| JA6825 | 25U | 600 × 800 | 1235 | 0.856 | 0.279 |
| JA6125 | 25U | 600 × 1000 | 1235 | 1.036 | 0.294 |
| JA6842 | 42U | 600 × 800 | 1991 | 1.323 | 0.045 |
| JA6142 | 42U | 600 × 1000 | 1991 | 1.601 | 0.477 |
| JA6848 | 48U | 600 × 800 | 2258 | 1.488 | 0.51 |
| JA6148 | 48U | 600 × 1000 | 2258 | 1.801 | 0.538 |
| JA8142 | 42U | 800 × 1000 | 1991 | 1.971 | 0.62 |
| JA8148 | 48U | 800 × 1000 | 2258 | 2.271 | 0.7 |
Flat-packed across five packages (front, rear, side panels, rails/cable management, beams) to cut shipping volume, or delivered assembled. Standard colours black RAL 9005 and grey RAL 7035.
FAQ
JA — common questions
What depths does the JA server rack come in?
The JA is offered at 800 mm and 1000 mm depth, in 600 mm or 800 mm width, across 25U, 42U and 48U heights.
Can the JA ship flat-packed to save container space?
Yes. The JA flat-packs into five packages. Flat-pack roughly halves the shipping volume versus an assembled cabinet, so you load far more racks per container.
What is the static load rating of the JA?
The JA is rated for an 800 kg static load, built on a 2.0 mm cold-rolled steel frame.
Quote the JA for your market
Send models, quantities, colour or label, and destination port.
