GWC welded wall cabinet — 4U–18U 19-inch enclosure, ships assembled
The GWC is a fully welded 19 inch wall cabinet that arrives assembled and ready to hang. The welded frame gives high rigidity for permanent installs, with a tempered-glass or vented-steel front door that opens beyond 180°, in six heights from 4U to 18U at 450 or 600 mm depth.
- Rack units4 / 6 / 9 / 12 / 15 / 18U
- Width × Depth600 × 450·600 mm
- Static load60 kg
Built for the job
- Fully welded frame for high rigidity — arrives fully assembled, no build-up on site.
- Front door in tempered glass or vented steel, opening beyond 180°, on a steel frame with a two-key cam lock.
- SPCC cold-rolled steel throughout; 60 kg static load.
- Closable cable entry top and bottom.
- Six heights (4U–18U), 600 mm wide, at 450 or 600 mm depth.
- Standard finish black RAL 9005 or grey RAL 7035.
Models & dimensions
The current GWC model matrix from the Grantec spec sheet — every width, depth and height we ship.
| Model | U | W × D (mm) |
|---|---|---|
| GWC6404 | 4U | 600 × 450 |
| GWC6604 | 4U | 600 × 600 |
| GWC6406 | 6U | 600 × 450 |
| GWC6606 | 6U | 600 × 600 |
| GWC6409 | 9U | 600 × 450 |
| GWC6609 | 9U | 600 × 600 |
| GWC6412 | 12U | 600 × 450 |
| GWC6612 | 12U | 600 × 600 |
| GWC6415 | 15U | 600 × 450 |
| GWC6615 | 15U | 600 × 600 |
| GWC6418 | 18U | 600 × 450 |
| GWC6618 | 18U | 600 × 600 |
The welded GWC arrives fully assembled. Black RAL 9005 or grey RAL 7035 as standard; other RAL on request.
FAQ
GWC — common questions
Does the GWC ship assembled or flat-packed?
The GWC has a fully welded frame and arrives assembled — there is no on-site build-up. For a flat-packing wall cabinet, choose the bolted GWA instead.
What front door does the GWC use?
A tempered-glass or vented-steel door on a steel frame with a two-key cam lock, opening beyond 180° for easy access.
