Wall-mount racks
QA wall-mount rack — 6U / 9U / 12U / 15U 19-inch network cabinet
The QA is a fully enclosed 19-inch wall-mount cabinet for edge, office and light network sites. It hangs on the wall in 6U, 9U, 12U and 15U at a shallow 450 mm depth, with a lockable tempered-glass door that reverses to open from either side.
- Rack units6 / 9 / 12 / 15U
- Width × Depth600 × 450 mm
- Static load60 kg
- Flat-pack from0.07 m³
More racks per container. Per-model assembled and flat-pack volumes in the table below.
Built for the job
- Fully enclosed cabinet with top cover, bottom plate and removable side panels.
- 5 mm tempered-glass front door, lockable, and reversible to hinge left or right to suit the wall.
- Fan-ready top cover and closable top/bottom cable entry for a tidy install.
- 60 kg static load; adjustable front and rear profile rails with an internal grounding screw.
- 600 mm wide, 450 mm deep — fits switches, patch panels and a short server in tight spaces.
- Door options: tempered glass (B / C / L) or solid iron (D).
Models & dimensions
Transcribed from the factory spec sheet. Assembled and flat-pack carton volumes let you compare container loading directly.
| Model | U | W × D (mm) | Height (mm) | Assembled (m³) | Flat-pack (m³) |
|---|---|---|---|---|---|
| QA6406 | 6U | 600 × 450 | 370 | 0.114 | 0.073 |
| QA6409 | 9U | 600 × 450 | 500 | 0.154 | 0.082 |
| QA6412 | 12U | 600 × 450 | 636 | 0.192 | 0.07 |
| QA6415 | 15U | 600 × 450 | 770 | 0.23 | 0.083 |
Ships flat-packed or assembled; both carton volumes are published per model. Black RAL 9005 or grey RAL 7035.
FAQ
QA — common questions
Can the QA door open from either side?
Yes. The tempered-glass door is reversible, so it hinges left or right to suit the wall and the room.
How deep is the QA wall cabinet?
A shallow 450 mm — deep enough for switches, patch panels and short-depth servers while staying close to the wall.
Quote the QA for your market
Send models, quantities, colour or label, and destination port.
